Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machinery. They produce machinery such as aerial lifts, manlifts and boom lifts. These types of machines are designed to facilitate access to places that are difficult to reach, large equipment, buildings and roofs, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and includes handholds or platforms or steps that are connected to the unit to be able to move workers from every floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is about 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
